Close loop compensation technique for high performance MPPT using ripple correlation control

S.M. Ferdous; GM. Shafiullah; M.A.M. Oninda; Md.A. Shoeb; T. Jamal

doi:10.1109/aupec.2017.8282429

Back

Conference paper

Close loop compensation technique for high performance MPPT using ripple correlation control

S.M. Ferdous, GM. Shafiullah, M.A.M. Oninda, Md.A. Shoeb and T. Jamal

2017 Australasian Universities Power Engineering Conference (AUPEC)

Australasian Universities Power Engineering Conference (AUPEC) 2017 (Melbourne, VIC, 19/11/2017–22/11/2017)

2017

DOI: https://doi.org/10.1109/aupec.2017.8282429

Files and links (1)

url

Link to Published Version *Subscription may be requiredView

Abstract

Conventional RCC uses Type-I compensator or Integrator which cannot track the Maximum Power Point (MPP) for all the operating condition without Adaptive Gain Tuning. The Type-II compensator based closed loop control scheme of the proposed MPPT makes it robust against all types of disturbances, panel and plant parameter variations. The RCC technique is very simple to implement and the total MPPT controller can be easily implemented using analog circuitry only. However, the challenge lies in designing the compensator as the RCC technique, along with PV panel, exhibits highly non-linear dynamics. Conventional Bode plot technique is used for designing the compensator where the plant parameters (Gain and Phase) are obtained by perturbing the panel operation around the MPP at crossover frequency. This paper proposes a compensator based implementation of Dynamic Maximum Power Point Tracking (MPPT) for rapidly changing irradiation and load variation using Ripple Correlation Control (RCC) technique. The proposed control scheme has a very fast convergence and is very prompt in tracking irradiance variation and load disturbance rejection. The efficacy of the proposed MPPT and the compensator are verified by simulation.

Details

Title: Close loop compensation technique for high performance MPPT using ripple correlation control
Authors/Creators: S.M. Ferdous (Author/Creator) - Murdoch University
GM. Shafiullah (Author/Creator) - Murdoch University
M.A.M. Oninda (Author/Creator) - Islamic University of Technology
Md.A. Shoeb (Author/Creator) - Murdoch University
T. Jamal (Author/Creator) - Murdoch University
Publication Details: 2017 Australasian Universities Power Engineering Conference (AUPEC)
Conference: Australasian Universities Power Engineering Conference (AUPEC) 2017 (Melbourne, VIC, 19/11/2017–22/11/2017)
Identifiers: 991005543451607891
Murdoch Affiliation: School of Engineering and Information Technology
Language: English
Resource Type: Conference paper
